WIKA压力变送器

德国wika S-11 平嵌隔膜式压力变送器德国威卡
应用

一般工业应用

食品和饮料行业

灌装和包装设备

定量给料技术

液位测量

功能特性

高质量产品

多种配置

平嵌隔膜过程连接件

大量库存，可短时间内交付

真空密封

描述

专门用于粘性和含固体颗粒的介质中。

S-11型压力变送器带平嵌隔膜，专门设计用于测量在粘性、浆糊状、粘合剂、结晶化、含微粒和受***等能够堵塞传统过程连接件压力通道的介质。

该型号变送器采用优化设计，使用了平嵌隔膜过程连接件，在过程连接件中集成了接液隔膜的清洁性。这样一来，使得该型号变送器即使用于经常更换介质的关键应用中，同样实现了低维护和无故障压力测量。

S-11型变送器的主要特点包括：高精度、坚固耐用、高品质制造和高灵活性的配置。

平嵌隔膜过程连接件

平嵌隔膜式压力变送器的所有过程连接件都由不锈钢制成，完全焊接并且通过可靠密封与压力测量仪表的压力介质隔离，确保了过程连接件与测量介质之间的可靠、无死区密封。

对于介质温度高达150°C的应用，该压力变送器还可以使用集成的冷却元件。

针对食品和饮料行业应用，我们可提供符合FDA 21 CFR 178.3750标准的内置有充液系统的变送器。

Description

Expert for viscous and particle-laden media

The model S-11 pressure transmitter with flush diaphragm

has been specifically designed for the measurement of

viscous, paste-like, adhesive, crystallising, particle-laden and

contaminated media, which would clog the pressure channel

of conventional process connections.

Through its optimised design, the flush process connection

enables cleanability with the wetted diaphragm integrated

into the process. Low-maintenance and trouble-free pressure

measurement is thus also guaranteed in critical applications

with frequently changing media.

High accuracy, a robust design, high-quality workmanship

and the high flexibility of configuration are key features of the

model S-11.

Flush process connection

All process connections of the flush pressure transmitter

are made of stainless steel and are fully welded and isolate

the medium from the pressure measuring instrument via a

positive seal. A reliable, dead-space free sealing between

the process connection and the measuring medium is thus

assured.

For high medium temperatures of up to 150 °C (302 °F),

the pressure transmitter is also available with an integrated

cooling element.

Specifically for the food and beverage industry, a version

with internal system fill fluid in accordance with FDA 21 CFR

178.3750 can be chosen.
