WIKA机械压力仪表

232.30.063安全型压力表 德国WIKA压力表233.30.063

wika常用型号
232.30.063 2.5 MPa 1/4 NPT lower mount
232.30.063 200 kg/cm2 1/4 NPT lower mount
232.30.063 4 kg/cm2 1/4 NPT lower mount
232.30.063 6 bar G1/4B lower mount
232.30.063 7 barg 2nd scale psig 1/4 NPT lower mount
232.30.100 0.6 MPa 1/2 NPT lower mount
232.30.100 1.6 bar 1/2 NPT lower mount
232.30.100 1.6 barg 1/4 NPT lower mount inductiv action,
232.30.100 1.6 MPa 2nd scale bar G1/2B lower mount
232.30.100 -1/+15 bar G1/2B lower mount
232.30.100 10 bar 1/2 NPT lower mount
232.30.100 10 bar 2nd scale MPa diaphragm seal lower moun
232.30.100 10 bar 2nd scale psi 1/2 NPT lower mount
232.30.100 10 MPa 1/2 NPT lower mount

技术参数
符合EN 837-1标准
标准尺寸 (mm)：63、100和160
准确度等级
NS 63：1.6
NS 100和160：1.0
量程：
NS 63：0 ... 0.1至0 ... 100 MPa
NS 100：0 ... 0.06至0 ... 100 MPa
NS 160：0 ... 0.06至0 ... 160 MPa或所有其他同等负压量程或正压和负压联程
