232.50.063不锈钢压力表德国wika销售 233.50.063-德国WIKA(www.weikayb.com)

232.50.063不锈钢压力表德国wika销售 233.50.063

仪器名称：232.50.063不锈钢压力表德国wika销售 233.50.063

仪器类别：WIKA机械压力仪表

市场价格：洽谈

咨询电话：029-86691808 88623902 传真：029-88638823-810

232.50.063不锈钢压力表德国wika销售 233.50.063

常用型号

232.50.063 special range 0...200 psi/MPa 1/4 NPT lower mount

232.50.063 special range 0...1000 psi/MPa 1/4 NPT lower mount

232.50.063 special range -1...6Barg 1/4 NPT lower mount

232.50.100 0.06 MPa 1/2 NPT lower mount

232.50.100 -0.1/+0.06 MPa Diaphragm Seal lower mount

232.50.100 0.16 MPa 1/2 NPT lower mount

232.50.100 0.25 MPa G1/2A lower mount inductiv action mo

232.50.100 0.4 MPa M20 x 1.5 lower back mount

232.50.160 25 MPa M20 x 1.5 lower mount

232.50.160 -30 inHg/+30 psi 1/2 NPT lower mount

232.50.160 40 bar G1/2B lower mount

232.50.160 400 bar G1/2B lower mount with alarm-contact

232.50.160 60 bar M20 x 1.5 lower mount

232.50.160 60 kPa 1/2 NPT lower mount

技术参数

标准尺寸 (mm)

63、100和160

准确度等级

NS 63：1.6

NS 100和160：1.0

量程：

NS 63：0 ... 0.1至0 ... 100 MPa

NS 100：0 ... 0.06至0 ... 100 MPa

NS 160：0 ... 0.06至0 ... 160 MPa

或所有其他同等负压量程或正压和负压联程

测量系统316L

防护等级：IP 65
