WIKA机械压力仪表

232.50.100不锈钢压力表 威卡wika压力表233.50.100
常用型号
232.50.063 -0.1/+0.2 MPa G1/4B lower mount 232.50.063 2.5 MPa 2nd scale bar diaphragm seal lower mou
232.50.063 -0.1/+0.5 MPa 1/4 NPT lower mount 232.50.063 20 MPa Diaphragm Seal center back mount
232.50.063 -0.1/+0.5 MPa G1/4B center back mount 232.50.063 20 MPa M14 x 1,5 lower mount
232.50.063 0.25 MPa G1/4B center back mount 232.50.063 200 psi 2nd scale MPa 1/4 NPT center back moun
232.50.100 0.4 MPa M20 x 1.5 lower back mount 232.50.100 16 kg/cm2 1/2 NPT lower mount
232.50.100 0.6 bar 1/2 NPT lower mount 232.50.100 160 kPa 0…12m (0m=1kpa, 10.5m=106kpa, 12m=121kp
232.50.100 -0.6 bar G1/2B lower mount 232.50.100 160 kPa 0…12m (0m=5kpa, 10.5m=110kpa, 12m=125kp
232.50.100 0.6 MPa 2nd scale bar M20 x 1.5 lower mount 232.50.100 160 kPa 2nd 0…12m (0m=2kpa, 10.5m=107kpa, 12m=1
232.50.100 0.6 MPa R 3/8-ISO7 (DIN2999) lower mount 232.50.100 2 bar Diaphragm Seal lower mount
232.50.160 -0.1/+0.3 MPa M20 x 1.5 lower back mount 232.50.160 2000 psi 2nd scale MPa 1/2 NPT lower mount
232.50.160 -0.1/+1 MPag 1/2 NPT lower mount 232.50.160 25 MPa M20 x 1.5 lower mount
232.50.160 0.16 MPa 1/2 NPT lower mount 232.50.160 -30 inHg/+30 psi 1/2 NPT lower mount
232.50.160 0.25 MPag 1/2 NPT lower mount 232.50.160 40 bar G1/2B lower mount
232.50.160 0.4 MPa M20 x 1.5 lower mount 232.50.160 400 bar G1/2B lower mount with alarm-contact
优化选型
其他过程连接
密封圈（910.17型，参见数据资料AC 09.08）
化学密封直接安装请看化学密封简易样本
蒙乃尔测量系统（26x.50型，不适合表圆直径160轴向安装接口）
表面或面板安装法兰，不锈钢
面板安装法兰，抛光不锈钢
三角凸边，不锈钢，抛光，带安装支架
环境温度-40℃：硅油充液
NS 100和160型带限位显示器
电接点压力表，PGS23.1x0型
详细参数
标准尺寸 (mm)：63、100和160
准确度等级
NS 63：1.6
NS 100和160：1.0
量程：
NS 63：0 ... 0.1至0 ... 100 MPa
NS 100：0 ... 0.06至0 ... 100 MPa
NS 160：0 ... 0.06至0 ... 160 MPa
测量系统：316不锈钢
入口保护：IP 65
