德国wika压力变送器P-30 威卡wika压力变送器
| 仪器名称：德国wika压力变送器P-30 威卡wika压力变送器 |
| 仪器类别：WIKA压力变送器 |
| 市场价格： 洽谈 |
| 咨询电话：029-86691808 88623902 传真：029-88638823-810 |
 在线业务
在线业务
在线业务
在线业务
在线业务 |
 |
德国wika压力变送器P-30 威卡wika压力变送器
应用
测量和实验平台
校准技术
实验室
设备建造和机械制造
常用型号
P-30 ; 0...1200 mbar abs; 0 ... 10 V, 3-wire
P-30 ; 0...16 MPa gauge; 4 ... 20 mA, 2-wire
P-30 ; 0...160 bar gauge; 4 ... 20 mA, 2-wire
P-30 ; 0...25 MPa gauge; 0 ... 10 V, 3-wire
P-30 ; 0...4 bar abs; 4 ... 20 mA, 2-wire
P-30 ; 0...4 MPa gauge; 4 ... 20 mA, 2-wire
P-30 ; 0...40 MPa gauge; 4 ... 20 mA, 2-wire
P-30 ; 0...400 bar gauge; 4 ... 20 mA, 2-wire
P-30 ; 0...600 bar gauge; 4 ... 20 mA, 2-wire
P-30 ; 0...600 mbar gauge; 4 ... 20 mA, 3-wire
P-30 ; -1...+9 bar gauge; 0 ... 10 V, 3-wire
技术参数
Pressure sensor for precision measurements Type P-30
Specifications according to data sheet: PE 81.54
Accuracy: 0.1% of span
Measuring range: 0...0.06 MPa gauge
Process connection: G 1/2 B
Special design for media: none
Output signal: 4 ... 20 mA, 2-wire
Electrical connection: circular connector M12x1, 4-pin
www.wika.com
Model name customer-specific: P-30
Pressure port: Standard
Permissible medium temperature: -20...+105°C
pin assignment el. connection: UB=1, 0V=3
shield: on case
Power supply: 9...30 V DC
应用
测量和实验平台
校准技术
实验室
设备建造和机械制造
常用型号
P-30 ; 0...1200 mbar abs; 0 ... 10 V, 3-wire
P-30 ; 0...16 MPa gauge; 4 ... 20 mA, 2-wire
P-30 ; 0...160 bar gauge; 4 ... 20 mA, 2-wire
P-30 ; 0...25 MPa gauge; 0 ... 10 V, 3-wire
P-30 ; 0...4 bar abs; 4 ... 20 mA, 2-wire
P-30 ; 0...4 MPa gauge; 4 ... 20 mA, 2-wire
P-30 ; 0...40 MPa gauge; 4 ... 20 mA, 2-wire
P-30 ; 0...400 bar gauge; 4 ... 20 mA, 2-wire
P-30 ; 0...600 bar gauge; 4 ... 20 mA, 2-wire
P-30 ; 0...600 mbar gauge; 4 ... 20 mA, 3-wire
P-30 ; -1...+9 bar gauge; 0 ... 10 V, 3-wire
技术参数
Pressure sensor for precision measurements Type P-30
Specifications according to data sheet: PE 81.54
Accuracy: 0.1% of span
Measuring range: 0...0.06 MPa gauge
Process connection: G 1/2 B
Special design for media: none
Output signal: 4 ... 20 mA, 2-wire
Electrical connection: circular connector M12x1, 4-pin
www.wika.com
Model name customer-specific: P-30
Pressure port: Standard
Permissible medium temperature: -20...+105°C
pin assignment el. connection: UB=1, 0V=3
shield: on case
Power supply: 9...30 V DC
